smart lighting
Magnetic Linear Dot Light
LY103-TLMLS magnetic linear dot light series is available in five wattage and length configurations. It uses Bridgelux LEDs with selectable beam angles and tunable colour temperature.
Key highlights
Designed for everyday control
Available in 12W
18W
24W
30W and 36W
Bridgelux LED
Product blueprint
Technical specifications
Core product, electrical, material, and installation details in one clear reference.
- model series
- LY103-TLMLS
- models
- LY103-TLMLS12W, LY103-TLMLS18W, LY103-TLMLS24W, LY103-TLMLS30W, LY103-TLMLS36W
- available wattages
- 12W, 18W, 24W, 30W, 36W
- material
- ALUMINUM DIE CASTING
- led brand
- BRIDGELUX
- beam angles
- 24°, 36°
- luminance
- 120 Lm/W
- cct
- 3000K to 6500K Tunable
- cri
- >90
- variants
- Model: LY103-TLMLS12W • Wattage: 12W • Dimensions: 22 × 222 × 44 mm, Model: LY103-TLMLS18W • Wattage: 18W • Dimensions: 32 × 322 × 44 mm, Model: LY103-TLMLS24W • Wattage: 24W • Dimensions: 43 × 422 × 44 mm, Model: LY103-TLMLS30W • Wattage: 30W • Dimensions: 54 × 522 × 44 mm, Model: LY103-TLMLS36W • Wattage: 36W • Dimensions: 65 × 622 × 44 mm
