smart lighting
Magnetic Straight Linear Light
LY103-MRMPS straight magnetic linear light series is available in four wattage and length configurations. The aluminum die-cast fixtures use Bridgelux LEDs with a wide beam and tunable colour temperature.
Key highlights
Designed for everyday control
Available in 10W
20W
30W and 40W
120° beam
Bridgelux LED
Product blueprint
Technical specifications
Core product, electrical, material, and installation details in one clear reference.
- model series
- LY103-MRMPS
- models
- LY103-MRMPS10W, LY103-MRMPS20W, LY103-MRMPS30W, LY103-MRMPS40W
- available wattages
- 10W, 20W, 30W, 40W
- material
- ALUMINUM DIE CASTING
- led brand
- BRIDGELUX
- beam angle
- 120°
- luminance
- 120 Lm/W
- cct
- 3000K to 6500K Tunable
- cri
- >90
- variants
- Model: LY103-MRMPS10W • Wattage: 10W • Dimensions: 300 × 22 × 44 mm, Model: LY103-MRMPS20W • Wattage: 20W • Dimensions: 600 × 22 × 44 mm, Model: LY103-MRMPS30W • Wattage: 30W • Dimensions: 900 × 22 × 44 mm, Model: LY103-MRMPS40W • Wattage: 40W • Dimensions: 1200 × 22 × 44 mm
